Bare welded control lines have become indispensable components in modern oil and gas well completions, offering enhanced reliability and operational efficiency. These specialized hydraulic conduits enable critical downhole functions while addressing challenges like corrosion resistance, pressure management, and long-term well integrity.
Bare welded control lines employ advanced manufacturing processes:
- Laser/TIG welding with post-weld drawing creates homogeneous microstructures
- Orbital welding techniques maintain consistent wall thickness (typically 0.028"-0.083")
- Cold working enhances yield strength by 15-20% compared to as-welded tubes
Common material specifications:
| Material | Yield Strength | Corrosion Resistance | Temperature Rating |
|---|---|---|---|
| 316L SS | 65 ksi | Moderate chlorides | 600°F |
| Alloy 625 | 110 ksi | H₂S/CO₂ environments | 1200°F |
| Duplex 2205 | 80 ksi | Seawater resistance | 570°F |
The absence of coatings eliminates potential failure points from encapsulation degradation, particularly in high-temperature downhole environments (250-350°F typical).
- Maintain 5,000 psi operating pressures for SCSSV systems
- 0.125" OD lines achieve response times <30 seconds at 10,000' depth
- Redundant welded paths prevent single-point failure modes
- 0.25" ID lines deliver precise dosage (0.1-5 GPM)
- Welded joints withstand cyclic pressure fluctuations (0-3,000 psi)
- Smooth internal finish (Ra<20 µin) prevents particulate buildup
- 13,500m continuous lengths with orbital welds
- Real-time data transmission through integrated fiber optics
- Maintain signal integrity in 15% H₂S environments
Critical production stages:
- EB/Argon shield welding minimizes oxide inclusion
- 100% eddy current testing on parent material
- Precision CNC forming (tolerance ±0.001")
- Automated purge gas monitoring during welding
- Sinking through diamond dies (20-40% area reduction)
- Solution annealing at 1900°F for stress relief
- 100% hydrostatic testing at 1.5x MAWP
Field data comparisons:
| Parameter | Bare Welded | Seamless | Encapsulated |
|---|---|---|---|
| Installation Time | 18 hrs | 22 hrs | 27 hrs |
| Failure Rate/1k ft | 0.03 | 0.05 | 0.12 |
| 10-Year Maintenance | $4.2k | $5.8k | $9.1k |
The elimination of encapsulation reduces deployment complexity while improving thermal transfer characteristics in ESP applications.
- 100% recyclable materials meet API RP 65 requirements
- Reduced ID surface area decreases chemical usage by 18%
- Laser welding consumes 40% less energy than conventional methods
Bare welded control lines represent a paradigm shift in downhole hydraulic system design. Their optimized manufacturing processes and material configurations address critical industry challenges including H₂S corrosion, deepwater pressure extremes, and extended service life requirements. As operators increasingly prioritize well integrity and operational efficiency, these systems continue displacing traditional encapsulated alternatives across both conventional and unconventional plays.
The homogeneous grain structure from post-weld cold working creates diffusion barriers 3-5x more effective than seamless equivalents. Combined with orbital welding's <0.1% porosity rate, this prevents microleakage even at 0.0001" clearance tolerances.
Implement:
- Annual annulus pressure monitoring
- Bi-annual control line function tests
- Downhole camera inspections every 5 years
- Fluid compatibility checks during workovers
Yes, using coiled tubing deployment methods. Typical retrofit parameters:
- Maximum depth: 20,000' TVD
- Bend radius: ≥48x OD
- Deployment rate: 500'/hr
Material-specific derating factors apply:
| Temp Range | 316L SS | Alloy 625 |
|---|---|---|
| 300-400°F | 0.95 | 1.00 |
| 400-500°F | 0.85 | 0.98 |
| 500-600°F | 0.70 | 0.95 |
Mandatory certifications include:
- API 5LC (CT-90/CT-110)
- NACE MR0175 Level III
- DNV-OS-F101 Appendix A
- ISO 13679 CAL IV
