Dear Customers,Our offered SS 2205 capillary tubing, which are mostly used for Liquid/ Gas Transportation Lines, Hydraulic control lines, Medical devices and equipment’s, Chromatography applications, Measurement devices, Remote thermometer systems Small precision stainless steel antenna, Watches, Car antenna tube, Laser engraving equipment, etc.As the largest stockholder of SS Capillary Tube includes grades SS 2205 Capillary Tubing, SS 304L Capillary Tube, Stainless Steel 316 Capillary Tubing, Stainless steel 316L Capillary Pipe and Stainless Steel 201 Capillary Pipe , we can guarantee the quality , offer you the best price, Sincerely hope we can cooperate!
We Supply Super A269 Alloy 2205 Stainless steel coiled tubing pipe/capillary tube, The manufacture of Stainless steel Super Duplex 2205 capillary tubing, which is designed to handle highly corrosive conditions and situations were high strength is required. High molybdenum, chromium and nitrogen content in Super Duplex 2205 help the material withstand pitting and crevice corrosion. The material is also resistant to chloride stress corrosion cracking, to erosion corrosion, to corrosion fatigue, to general corrosion in acids. This alloy has good weldability and very high mechanical strength.stainless steel grade Super Duplex 2205stainless steel coiled tubing /coiled tubes and A269 Duplex 2205 capillary tubing
Descriptions:2205/S31803 Control Line(Capillary Tubing),
PHYSICAL PROPERTIES
Yield strength: ≥80,000 psi
Tensile strength: ≥95,000 psi
Maximum Hardness: 30C Rockwell
OD：0.250”-0.625”
Wall Thk : 0.032”-0.065”
Length:Max. 15000M/PCS
Note: special specifications, materials and length of products can be customized according to customer requirements
Duplex 2205 Capillary Pipe CHEMICAL COMPOSITION ‐ %
Mo 3.0‐3.5
C≤0.030
Mn≤2.00
P≤0.030
Ni 4.5‐6.5
S≤0.020
Si≤1.00
Cr 21.0‐23.0
Commonly Size of stainless steel coiled tube: we can product them as your request.
Stainless Steel Capillary Tubing | ||||
ITEM | Grade | Size | Length | Pressure (Mpa) |
1 | 316L 304L 304 625 825 2205 2507 | 1/8″×0.025″ | 3200 | 80 |
2 | 316L 304L 304 625 825 2205 2507 | 1/8″×0.035″ | 3200 | 100 |
3 | 316L 304L 304 625 825 2205 2507 | 1/4″×0.035″ | 2000 | 100 |
4 | 316L 304L 304 625 825 2205 2507 | 1/4″×0.049″ | 2000 | 100 |
5 | 316L 304L 304 625 825 2205 2507 | 3/8″×0.035″ | 1500 | 80 |
6 | 316L 304L 304 625 825 2205 2507 | 3/8″×0.049″ | 1500 | 100 |
7 | 316L 304L 304 625 825 2205 2507 | 1/2″×0.049″ | 1000 | 80 |
8 | 316L 304L 304 625 825 2205 2507 | 1/2″×0.065″ | 1000 | 100 |
9 | 316L 304L 304 625 825 2205 2507 | φ3mm×0.7mm | 3200 | 80 |
10 | 316L 304L 304 625 825 2205 2507 | φ3mm×0.9mm | 3200 | 100 |
11 | 316L 304L 304 625 825 2205 2507 | φ4mm×0.9mm | 3000 | 100 |
12 | 316L 304L 304 625 825 2205 2507 | φ4mm×1.1mm | 3000 | 100 |
13 | 316L 304L 304 625 825 2205 2507 | φ6mm×0.9mm | 2000 | 100 |
14 | 316L 304L 304 625 825 2205 2507 | φ6mm×1.1mm | 2000 | 100 |
15 | 316L 304L 304 625 825 2205 2507 | φ8mm×1mm | 1800 | 80 |
16 | 316L 304L 304 625 825 2205 2507 | φ8mm×1.2mm | 1800 | 100 |
17 | 316L 304L 304 625 825 2205 2507 | φ10mm×1mm | 1500 | 70 |
18 | 316L 304L 304 625 825 2205 2507 | φ10mm×1.2mm | 1500 | 70 |
19 | 316L 304L 304 625 825 2205 2507 | φ10mm×2mm | 500 | 100 |
20 | 316L 304L 304 625 825 2205 2507 | φ12mm×1.5mm | 500 | 80 |
We offer Stainless Steel 2205 Capillary Tubing in small bore sizes and precise thickness are available as per the requirements of clients. Stainless Steel Capillary Tubes sizes range from 0.30 mm to 8.00 mm. They can be availed in standard or heavy wall Stainless Steel Duplex 2205 Capillary Tubing diameters of refrigerant capillary tubes range from 0.30 mm to 31.75 mm O.D. And 0.06 mm to 1.65 mm thickness and the length ranges from 1.0 mm to 6.0 mm. It is widely used in instrumentation Industries. Stainless Steel 304 capillary Pipes and Stainless Steel 316 capillary Pipes are available in precise cut to lengths are also highly effective in a wide range of temperatures. SS2205 capillary tubing is widely used for high-pressure applications.
Our offered SS 2205 capillary tubing are mostly used for Liquid/ Gas Transportation Lines, Hydraulic control lines, Medical devices and equipment’s, Chromatography applications, Measurement devices, Remote thermometer systems Small precision stainless steel antenna, Watches, Car antenna tube, Laser engraving equipment, etc.As the largest stockholder of SS Capillary Tube includes grades SS 2205 Capillary Tubing , SS 304L Capillary pipe, Stainless Steel 316 Capillary tube, Stainless steel 316L Capillary tube and Stainless Steel 201 Capillary Tubing those are used in various industrial applications.
We are the ALLOY 2205 Stainless steel coiled tubing , Duplex 2205coiled tubing China Suppliers, 2205 Capillary Pipe Manufacture in China.
| OD(INCH) | WALLTHICKNESS (INCH) | MIN TENSILE STRENGTH (PSI) | THEORETICAL BURST PRESSURE * (PSI) | WORKING PRESSURE (PSI) 25% OF BURST | THEORETICAL YIELD POINT ** (PSI) | COLLAPSE PRESSURE *** (PSI) | |
|---|---|---|---|---|---|---|---|
| 0.250 | 0.020 | 30,000 | 75,000 | 14,286 | 3,571 | 5,714 | 4,416 |
| 0.250 | 0.028 | 30,000 | 75,000 | 21,649 | 5,412 | 8,660 | 5,967 |
| 0.250 | 0.035 | 30,000 | 75,000 | 29,167 | 7,292 | 11,667 | 7,224 |
| 0.250 | 0.049 | 30,000 | 75,000 | 48,355 | 12,089 | 19,342 | 9,455 |
| 0.250 | 0.065 | 30,000 | 75,000 | 81,250 | 20,313 | 32,500 | 11,544 |
| 0.375 | 0.020 | 30,000 | 75,000 | 8,955 | 2,239 | 3,582 | 3,029 |
| 0.375 | 0.028 | 30,000 | 75,000 | 13,166 | 3,292 | 5,266 | 4,145 |
| 0.375 | 0.035 | 30,000 | 75,000 | 17,213 | 4,303 | 6,885 | 5,077 |
| 0.375 | 0.049 | 30,000 | 75,000 | 26,534 | 6,634 | 10,614 | 6,816 |
| 0.375 | 0.065 | 30,000 | 75,000 | 39,796 | 9,949 | 15,918 | 8,597 |
| 0.500 | 0.020 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.500 | 0.028 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.500 | 0.035 | 30,000 | 75,000 | 12,209 | 3,052 | 4,884 | 3,906 |
| 0.500 | 0.049 | 30,000 | 75,00 | 18,284 | 4,571 | 7,313 | 5,304 |
| 0.500 | 0.065 | 30,000 | 75,000 | 26,351 | 6,588 | 10,541 | 6,786 |
| 0.500 | 0.083 | 30,000 | 75,000 | 37,275 | 9,319 | 14,910 | 8,307 |
| 0.625 | 0.020 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.625 | 0.028 | 30,000 | 75,000 | 7,381 | 1,845 | 2,953 | 2,568 |
| 0.625 | 0.035 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 |
| 0.625 | 0.049 | 30,000 | 75,000 | 13,947 | 3,487 | 5,579 | 4,335 |
| 0.625 | 0.065 | 30,000 | 75,000 | 19,697 | 4,924 | 7,879 | 5,591 |
| 0.625 | 0.083 | 30,000 | 75,000 | 27,124 | 6,781 | 10,850 | 6,910 |
| 0.625 | 0.095 | 30,000 | 75,000 | 32,759 | 8,190 | 13,103 | 7,734 |
| 0.625 | 0.109 | 30,000 | 75,000 | 40,172 | 10,043 | 16,069 | 8,639 |
| 0.750 | 0.028 | 30,000 | 75,000 | 6,052 | 1,513 | 2,421 | 2,156 |
| 0.750 | 0.035 | 30,000 | 75,000 | 7,721 | 1,930 | 3,088 | 2,669 |
| 0.750 | 0.049 | 30,000 | 75,000 | 11,273 | 2,818 | 4,509 | 3,664 |
| 0.750 | 0.065 | 30,000 | 75,000 | 15,726 | 3,931 | 6,290 | 4,749 |
| 0.750 | 0.083 | 30,000 | 75,000 | 21,318 | 5,330 | 8,527 | 5,905 |
| 0.750 | 0.095 | 30,000 | 75,000 | 25,446 | 6,362 | 10,179 | 6,637 |
| 0.750 | 0.109 | 30,000 | 75,000 | 30,733 | 7,683 | 12,293 | 7,453 |
| 0.750 | 0.120 | 30,000 | 75,000 | 35,294 | 8,824 | 14,118 | 8,064 |
| 0.875 | 0.020 | 30,000 | 75,000 | 3,593 | 898 | 1,437 | 1,340 |
| 0.875 | 0.028 | 30,000 | 75,000 | 5,128 | 1,282 | 2,051 | 1,859 |
| 0.875 | 0.035 | 30,000 | 75,000 | 6,522 | 1,630 | 2,609 | 2,304 |
| 0.049 | 30,000 | 75,000 | 9,459 | 2,365 | 3,784 | 3,172 | |
| 0.875 | 0.065 | 30,000 | 75,000 | 13,087 | 3,272 | 5,235 | 4,126 |
| 0.875 | 0.083 | 30,000 | 75,000 | 17,560 | 4,390 | 7,024 | 5,152 |
| 0.875 | 0.095 | 30,000 | 75,000 | 20,803 | 5,201 | 8,321 | 5,807 |
| 0.875 | 0.109 | 30,000 | 75,000 | 24,886 | 6,221 | 9,954 | 6,543 |
| 0.875 | 0.120 | 30,000 | 75,000 | 28,346 | 7,087 | 11,339 | 7,100 |
| 1.000 | 0.028 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.000 | 0.035 | 30,000 | 75,000 | 5,645 | 1,411 | 2,258 | 2,027 |
| 1.000 | 0.049 | 30,000 | 75,000 | 8,149 | 2,037 | 3,259 | 2,796 |
| 1.000 | 0.065 | 30,000 | 75,000 | 11,207 | 2,802 | 4,483 | 3,647 |
| 1.000 | 0.083 | 30,000 | 75,000 | 14,928 | 3,732 | 5,971 | 4,567 |
| 1.000 | 0.095 | 30,000 | 75,000 | 17,593 | 4,398 | 7,037 | 5,159 |
| 1.000 | 0.109 | 30,000 | 75,000 | 20,908 | 5,227 | 8,363 | 5,827 |
| 1.000 | 0.120 | 30,000 | 75,000 | 23,684 | 5,921 | 9,474 | 6,336 |
| 1.000 | 0.134 | 30,000 | 75,000 | 27,459 | 6,865 | 10,984 | 6,963 |
| 1.250 | 0.035 | 30,000 | 75,000 | 4,449 | 1,112 | 1,780 | 1,633 |
| 1.250 | 0.049 | 30,000 | 75,000 | 6,380 | 1,595 | 2,552 | 2,260 |
| SIZE OD | NOMINAL WALL THICKNESS | OUTSIDE DIAMETER TOLERANCE | LENGTH TOLERANCE | WALL THICKNESS TOLERANCE | ||||
|---|---|---|---|---|---|---|---|---|
| (in) | (mm) | (in) | (mm) | (in) | (mm) | (in) | (mm) | (%) |
| ½ | 12.7 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| ¾ | 19.1 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1 | 25.4 | 0.065 | 1.65 | +/-0.005 | +/-0.13 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 1½ | 38.1 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2 | 50.8 | 0.065 | 1.65 | +/-0.008 | +/-0.20 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 2½ | 63.5 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 3 | 76.2 | 0.065 | 1.65 | +/-0.010 | +/-0.25 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 4 | 101.6 | 0.083 | 2.11 | +/-0.015 | +/-0.38 | +⅛, -0 | +3.18, -0 | +/-10.0% |
| 6 | 152.4 | 0.109 | 2.77 | +/-0.030 | +/-0.76 | +1, -0 | +25.4, -0 | +/-10.0% |
| 304 | 310 |
| 304L | 316 |
| 304H | 316L |
| 309 | 316Ti |
| 310 | 321/321H |
| 310S | 347/347H |
| 316 | 304 |
| 316L | 304L |
| 316Ti | 304H |
| 321/321H | 309 |
| 347/347H | 310 |
| 304 | 310S |
| 304L | 316 |
| 304H | 316L |
| 309 | 316Ti |
| 310 | 321/321H |
These stainless steel 2205 Capillary Tubing are sold to a wide range of industries/markets, due to their overall corrosion resistance and good machinability:
Stainless Steel Capillary Tubing for Chemical and petrochemical
SS Capillary tube used for Power generation
Stainless Steel Capillary Pipe for Renewable energy
SS Capillary Tubing for Pulp and Paper
SS Capillary Tube for Process piping
Stainless Steel Capillary Pipe applications for Food and beverage
SS Capillary Pipe used for Oil and gas
Stainless Steel Capillary Tube applications in Mining
SS Capillary Tubing used for Water/waste
Stainless Steel Capillary Pipe application for Marine Industry
